Daim ntawv qhia
Specification parameter | Paub meej | Lus ceeb toom |
Sheath Material | SUS 304 | Khoom siv tooj liab, sus321, sus316L, incoloy804, incoloy800as thov |
Voltage / lub zog | 220V5000W | Voltage / Wattage / Tolerance tuaj yeem kho raws li qhov xav tau, thiab Wattage kam rau ua (txias txias) ntxiv rau 5 feem pua -10 feem pua |
Tube Dia | 6.5 hli / 8.5mm | Tube txoj kab uas hla tuaj yeem hloov mus rau 6.6mm, 7mm, 8.0mm, 8.5mm, 10mm lossis lwm yam raws li kev thov |
Cov hmoov tsis kam | Magnesium oxide | Peb tuaj yeem siv lwm cov hmoov yog tias thov |
Resistance Hlau | Ni80Cr20 | Ocr25Al5 lossis lwm yam khoom siv yog thov |
Faston Terminal | Nickel plated hlau | Cov khoom ntawm lub davhlau ya nyob twg yuav yog cov hlau tsis muaj steel, stainless hlau yog tias xav tau |
Coj | Stainless hlau | Cov ntaub ntawv ntawm lub davhlau ya nyob twg yuav yog cov hlau tsis muaj hlau, stainless hlau yog tias xav tau |
Ntsia Hlau Xov | 1 "los yog 2" | Lwm cov xov tuaj yeem ua yog tias xav tau |
Qhov ntom | Max 30W / cm2 | |
Cov duab | U lossis lwm yam raws li qhov xav tau | |
Kev piav qhia
Qhib coil cua cua sov cov ntsiab lus yog cov khoom siv hluav taws xob muaj txiaj ntsig zoo tshaj plaws thiab kev lag luam zoo tshaj plaws rau kev siv cua sov feem ntau. Siv feem ntau hauv kev lag luam cua sov, qhib coil cua sov cov ntsiab lus muaj qhib circuits uas cua sov ncaj qha los ntawm kev tshem tawm cov coils. Cov khoom siv cua sov no muaj lub sijhawm kub ceev uas txhim kho kev ua haujlwm zoo thiab tau tsim los rau kev saib xyuas qis thiab yooj yim, pheej yig hloov qhov chaw.
Cov hlau tsis muaj zog nyob rau hauv qhov loj me thiab lub zog ntom ntom (ohm / meter), qhov txhab thiab zoo li tus neeg siv khoom xav tau. Feem ntau yog coiled nyob rau hauv kauv duab thiab siv nyob rau hauv hluav taws xob rauv qhov kub txog li 1100◦C yuav tsum tau.
Qhib coil cua sov cov ntsiab lus feem ntau yog tsim rau cov txheej txheem cua sov, yuam cua & ncu thiab rau cov yeeb nkab cua sov daim ntaub ntawv. Qhib coil rhaub cov ntsiab lus yog tsim kom haum rau hauv tus qauv 2 '' lossis 3 '' lub sijhawm 40 NPS yeeb nkab. Lawv yog siv nyob rau hauv lub tank thiab yeeb nkab cua sov thiab / los yog hlau tubing. Qhov tsawg kawg nkaus clearance ntawm 1/8 '' yog yuav tsum tau ntawm cov ceramic thiab sab hauv phab ntsa ntawm lub raj. Txhim kho qhov qhib coil caij yuav muab cov khoom siv hluav taws xob zoo tshaj plaws thiab zoo sib xws ntawm thaj chaw loj.
Qhib coil cua sov cov ntsiab lus yog ib qho indirect industrial cua sov tov kom txo watt ceev yuav tsum tau los yog lub tshav kub fluxes nyob rau hauv lub cheeb tsam ntawm cov yeeb nkab txuas mus rau lub rhuab seem thiab tiv thaiv tshav kub cov ntaub ntawv los ntawm coking los yog tawg.
Khoom nthuav dav
Nta
* Qib siab, kub kub hlau uas muaj qhov ruaj khov thiab tsis sib xws thaum lub sijhawm ua haujlwm ntev * Kev xaiv dav ntawm cov hlau loj ntawm Ø1mm thiab Ø6mm kom ua tiav cov neeg siv khoom xav tau * Kev cai-tsim, pre-assembled bracket-mounted cua sov hlau tuaj yeem tsim raws li rau cov neeg siv khoom tshwj xeeb * qib siab, siab kub Ni-chrome lossis Fe-chrome kuj xaim
Daim ntawv thov
Hluav taws xob rauv
Cua-duct cua sovOvens & furnaces
Chav cua txias
Cov khoom siv cua sov cua sov-tswj siv Mini-dryers
Cim npe nrov: qhib coil cua kub ntsiab lus, Tuam Tshoj, lwm tus neeg, manufacturers, hoobkas, customized, lag luam wholesale, dawb qauv, ua nyob rau hauv Suav teb
